Fiberglass Rebar

Clearco Fasteners is a distributor of SFTec's fiberglass rebar.  Call (952) 582-4895 for more information.

Check out http://sftec.com for more information.


SFT-Bar is

ICC-ES Evaluated

Report #ESR-5081


  • Slide title

    Write your caption here
    Button

  • Slide title

    Write your caption here
    Button

SFTec-Bar has many advantages and a few of them are listed below...


  • The Structural bar is ICC rated for #3, #4, #5, and #6 sizes.
  • It is significantly lighter than traditional steel rebar and has been tested to be about twice as strong.
  • It meets all necessary testing and ratings for use in slabs and vertical cement walls, including ICF.
  • The bar features a grey color that resembles steel rebar.
  • It is well-coated to prevent you from getting fiber slivers.
  • Available in both nonstructural G40 and structural G60 options.




Designated Diameter Nominal Cross-sectional Area Guaranteed Tensile Strength Tensil Modulus of Elasticity Transverse Shear Strength
(CSA S807 Table 1) (CSA S807 Table 1) (ASTM D7205) (ASTM D7205) (ASTM D7617)
Diameter in mm mm2 MPa GPa kN
6 32 1105 46-70 7
8 50 1050 46-70 23
10 71 1002 46-70 31
13 129 981 46-70 54
15 199 960 46-70 79
20 284 898 46-70 109
22 387 877 46-70 156
25 510 843 46-70 188
